GLFILL Bms 7S 24V 10A 20A 30A Lithium Battery Protection Board With Battery Balancer

BMS 7S 24V 10A 15A 20A 30A Lithium Battery Protection Board with Battery Balancer Li-ion Pack BMS for Power Bank Charge Specification: Type: 7S 24V Connection method: Common Port Discharge: Single battery over-discharge voltage: 2.7V±0.08V Continuous working current: 10A/20A/30A Instant protection current: 25A/50A/70A Overcurrent recovery conditions: charge recovery or disconnect load Short-circuit recovery conditions: charge recovery or disconnect load Charge: Single battery overcharge voltage: 4.25V±0.025V Continuous charging current: 10A/20A/30A Charge equalization voltage: 4.15V±0.025V Charge equalization current：40mA Charger voltage: 30V (recommended) Charging over temperature protection: 50℃ Discharge over temperature protection: 70℃ Working power consumption: ≤30uA Main circuit conduction internal resistance: ≤50mΩ Temperature range: -40 to 80℃ Wire break protection: Yes Appearance size: 108*34*2.8MM Package: 1 x Lithium Battery Protection Board Notes: Due to the light and screen setting difference the item s color may be slightly different from the pictures. Please allow slight dimension difference due to different manual measurement.
