ESP-01D ESP8285 WiFi Module Serial Port to WiFi Wireless Transparent Transmission Small Size Board

Feature 1 Complete 802 1 1b g n WIFI SOC module2 Built in Tensilica L106 ultra low power consumption 32 bit micro MCU main frequency supports 80 MHz and 160 MHz supports RTOS3 Support GPI0 PWM interface4 Built in Flash5 Adopt DIP 16 package6 Integrated Wi Fi MAC BB RF PA LNA7 Support multiple sleep modes8 Embedded Lwip protocol cable9 Support STA AP STA AP working mode10 Support Android IOS Smart Config APP Airkiss WeChat one click network configuration11 Support remote firmware upgrade F0TA 12 General AT commands can be used quickly13 Support secondary development integrated Windows Linux development environmentModelESP 01ESP 01D This item ESP 01FESP 01MESP 01SESP 07Letter of agreementComplete 802 11b g n WiFi SoC moduleWorking frequency2400 2483 5MHzChip schemeESP8266ESP8285ESP8285ESP8285ESP8266ESP8266Antenna formOnboard antennaExternal antennaExternal antennaOnboard antennaOnboard antennaIPEX seat ceramic antennaPackage formDIP 8DIP 6SMD 18DIP 18DIP 8SMD 16Size mm 24 7 14 4 11 013 5 8 5 2 611 0 10 0 2 018 0 18 0 2 824 4 14 4 11 221 2 16 0 3 0Serial port rate4Mbps4Mbps4Mbps4Mbps4Mbps4MbpsTransmission distance50 meters40 meters50 meters40 meters50 meters50 metersSupply voltagePower supply voltage 3 0 3 6V typical value 3 3VSPI Flash8Mbit16Mbit8Mbit 16Mbit8Mbit 16Mbit8Mbit8MbitIO port2391129Module certificationNONOFCC CEFCC CE SRRC REACH RoHsROHSNOModem Sleep20mA20mA20mA20mA20mA20mALight Sleep2mA2mA2mA2mA2mA2mADeep Sleep20uA20uA20uA20uA20uA20uAModule
