ESCAM WNK803 8CH 720P Wireless NVR Kit Outdoor IR WiFi IP Camera Surveillance Home Security System (Adaptor: EU Plug)

Features : High definition image quality, resolution up to 1 Megapixel, 1280*720. Power on, images out, plug in and play. WiFi range up to 50 meters. WiFi connection, without wiring. Dual antenna WiFi NVR. Specification : ESCAM WNK803 Wireless NVR video input Network Video 8CH Network video input broadbank 20Mbps video output HDMI input 1ch, resolution: 1024x768, 1366x768, 1440x900, 1920x1080p VGA output 1ch, resolution: 1024x768, 1366x768, 1440x900, 1920x1080p AV CODEC Video Resolution 720P synch-playback 4CH Video Control Video/Capture mode Maual / Time / Motion / Alarm Playback mode Real time / Routine / Event Backup USB backup Hard Disk Type 1*SATA interface Max Capacity 4 TB at most for each External Interface Network Interface one adaptable RJ45 10M/100M, one 2.4Ghz WIFI interface USB Interface USB 2.0 Network Control Protocol UPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up) DHCP (Automatically obtain an IP address) Others Power Supply DC12V 2A Power Consumption (W) ≤5W (Without HDD) Operate Temperature (°C) -10? to +55? Working Humidity (%) RH 10% - 90% Weight (excluding HDD) 0.73Kg Dimensions 257x210x42mm IP Camera Sensor 1/4” Progressive CMSO Sensor Signal System PAL/NTSC Resolution 1280 x 720 Minimum illumination Color: 0.1 Lux; B/W: 0.01 Lux Shutter 1/25s to 1/25,000s Lens 3.6mm OSD Date Time & Title White Balance Auto Day&Night Auto / Color / BW 3D-DNR Auto Mirror/Flip On / Off Frame Specification Three Streaming at the Same Time: H.264 1280x720@15fps or below H.264 640x480@30fps or below S/N > 39.1 Db Interface RJ45 / WIFI 802.11b/g/n General Anti-thunder Level Standard IEC61000-4-5 Working Temperature/Humidity -10? to +50? / 30% to 80% RH Working Temperature/Humidity -20? to +60? / 20% to 90% RH Power Input DC12V 1A Power consumption ≤6W Level of Protection IP66 Weight 0.25kg Dimensions 107 x 68 x 60mm Package Package Dimension 320 x 280 x 280mm Package Weight 5kg Package includeds : 1 x ESCAM WNK803 WiFi NVR 8 x WIFI Camera 9 x Screw Bag 1 x Mouse 9 x Power Adapter (EU/US/AU/UK Plug for Optional~) 1 x User Manual 8 x Waterproof Hat 1 x Network Cable Details pictures :
