433Mhz SI4463 100mW Wireless Data Transceiver Module 2000-meter Long Distance Wireless Module SPI RF Module

Module introduction: AS10-M4463D-SMA is a 100mW wireless transceiver integrated data transmission module with high stability, strong diffraction performance, excellent wall through ability working on 433MHz. It is designed and developed by using the original SI4463 RF chip imported from American Silicon Lab with high receiving sensitivity and good anti-interference ability. The SMA interface is used to match the high performance antenna, and the accurate impedance matching network is designed which makes the module have enough power to transmit, good spectrum, small harmonics,small channel crosstalk and small volume. Sensing devices all use Murata B level material, together with 10ppm high-precision crystal, it is the industrial standard model. Electric Parameters: NO. Parameter name Parameter values Abstract 1 RF chip SI4463 Silicon Labs 2 Module size 24*16 mm Not including SMA 3 Module weight 3.4g Including SMA 4 Operate frequency 425M~525MHz Can be adjusted by software, the module uses 30M crystal 5 Production craft Lead-free environmental protection process 6 Interface mode 2 * 6 * 2.54mm Plug-in 7 Supply voltage 1.8 ~ 3.6V DC voltage higher than 3.6V will damage the module permanently 8 Communication level 0.7VCC ~ 3.6V VCC refers to the module supply voltage 9 Measured distance 2000m Clear and open, maximum power,height 1.5m, 1k air speed 10 Sending power Maximum 20dBm About 100mW 11 Air rate 0.123k ~ 1Mbps It is adjustable by Software it is recommended to use low-speed as far as possible 12 Turn off current 0.5uA In power down mode 13 Sending current 80mA@100dBm Power supply must be more than 200mA 14 Receiving current 13mA Average value 15 Communication Interface SPI The maximum rate is up to 10Mbps 16 Transmitting length Single packet 1 to 64 bytes Single packet 17 Receiving length Single packet 1 to 64 bytes Single packet 18 RSSI support support See chip manual for detail 19 Antenna interface SMA-KE External thread inner hole 50 impedance 20 Operation temperature -40 ~ +85 Industrial grade 21 Operation humidity 10%-90% relative humidity, No condensation 22 Storage temperature -40 ~ +125 Industrial grade 23 Receiving sensitivity -126dBm @ 1kbps See the chip manual for details Package Included: 1 x Wireless Modules
