10pcs 1CH Channel Relay Module 5V For 250VAC/60VDC 10A Equipment Device RobotDyn for Arduino - products that work with o

Feature This is 1 channel Relay module can able to control various appliances and other equipment with a current not more 10A 250VAC 60VDC It can be controlled directly by microcontroller Raspberry AVR PIC DSP or TTL logic For control of module need power 5V and logic operation 5V For isolate the microcontroller from the relay we added optocoupler Now with this configuration the microcontroller doesn t have any physical connection with the relay it just uses the LED light of the Optocoupler IC to activate the relay This solution saves your microcontroller from a high voltage for VAC VDC Documents Dimensional drawing Click here to openPinout Click here to openSchematic Click here to openPackage included 10 x 5V Relay module
